Grinding Machine

Specification

MODEL	UNIT	PSG-820 ADS	PSG-618T	APSG-1020 2A / 3A / AD	APSG-1224 2A / 3A / AD
DESCRIPTION
TABLE SIZE	mm	200 x 500	150 x 460	250 x 500	300 x 600
MAX. GRINDING SURFACE	mm	230 x 580	150 x 450	250 x 500	300 x 600
MAX. DISTANCE CENTER OF SPINDLE TO TABLE	mm	400	420	510
TABLE GUIDEWAY		V & Flat Way
WHEEL SPEED / SPINDLE SPEED	rpm	2,850	3,000		1,450
SPINDLE MOTOR	HP	2 (Opt. 3)	1.5	3	5
WEIGHT	kgs	960	780	1,350	1,650
PACKING SIZE (L x W x H)	mm	1,900 x 1,700 x 2,100	1,450 x 1,100 x 2,100	1,800 x 1,600 x 2,100	2,200 x 1,900 x 2,100
